Gajjar Equipments Pvt. Ltd. is a reliable and trusted manufacturer, supplier and
Exporter of Mobile Asphalt Plant with Quick Installation in Tanzania.
Our manufacturing unit is based in Ahmedabad, Gujarat, India.
GAJJAR Mobile Drum Mix Plants are designed for high efficiency and flexibility in asphalt production.
With continuous asphalt mixing capabilities and a capacity range from 20 TPH to 160 TPH, these plants are perfect for temporary construction projects, remote job sites, and emergency road maintenance operations.
Compact, transport-optimized, and pre-wired for rapid setup, these mobile asphalt plants ensure high-quality pavement mix output without the need for permanent foundations.
Why Choose Our Mobile Asphalt Plant?
- Highly Mobile & Transport-Optimized: Trailer or skid-mounted design for easy relocation.
- Quick Installation: Pre-wired chassis enables fast deployment and start-up.
- Cost-Effective: Lower transportation and foundation costs.
- Flexible Production: Adjustable mixing time for different asphalt recipes.
- Reliable Quality: Clearly separated heating and mixing processes ensure consistent asphalt mix.
Features
- Compact and transport-friendly design for temporary or remote sites.
- Pre-wired chassis with junction box, kingpin system, and pneumatic braking.
- Adjustable mixing time for tailored asphalt production.
- High mixing efficiency and uniform asphalt quality.
- Complete production package including load-out conveyor and optional filler unit.
- Minimal foundation requirements, allowing rapid operational readiness.
Working Principles
- Weighing Virgin Aggregates: Accurate measurement of raw materials for precise mix.
- Drying and Heating: Aggregates are dried and heated to required temperature.
- Aggregate Flow and Mixing: Continuous flow ensures uniform mixing.
- Continuous Asphalt Production: On-site production of hotmix asphalt for immediate use.
Specifications
| Model | Rated Output (3% Moisture Content) | Mobility Arrangement – Chassis 1 | Chassis 2 | Chassis 3 | Chassis 4 | Standalone Components |
| MDMX-30 | 20 – 40 TPH | Bin Feeder, Dryer, Venturi Pollution Unit | Bitumen Tank, Fuel Tank | Prewired Control Panel with Cabin and Genset (Optional) | NA | Load Out Conveyor, GOB Hopper |
| MDMX-40 | 40 – 60 TPH | 4 Bin Feeder | Dryer with Pollution Control Unit | Bitumen Tank, Fuel Tank | Prewired Control Panel with Cabin and Genset (Optional) | Load Out Conveyor, GOB Hopper, Filler Unit |
| MDMX-50 | 60 – 90 TPH | 4 Bin Feeder | Dryer with Pollution Control Unit | Bitumen Tank, Fuel Tank | Prewired Control Panel with Cabin and Genset (Optional) | Load Out Conveyor, GOB Hopper, Filler Unit |
| MDMX-60 | 90 – 120 TPH | 4 Bin Feeder | Dryer with Pollution Control Unit | Bitumen Tank, Fuel Tank | Prewired Control Panel with Cabin and Genset (Optional) | Load Out Conveyor, GOB Hopper, Filler Unit |
| MDMX-65 | 120 – 160 TPH | 4 Bin Feeder | Dryer with Pollution Control Unit | Bitumen Tank, Fuel Tank | Prewired Control Panel with Cabin and Genset (Optional) | Load Out Conveyor, GOB Hopper, Filler Unit |
Applications
- Road construction and maintenance projects.
- Emergency asphalt repairs in remote locations.
- Temporary and short-term infrastructure projects.
- Projects requiring frequent site relocation.
Frequently Asked Questions (FAQs)
Q1: What is the main advantage of a mobile asphalt plant?
A1: It allows on-site asphalt production, reducing transportation costs and enabling rapid deployment in remote or temporary locations.
Q2: How quickly can the plant be installed?
A2: The pre-wired chassis design allows for quick installation, requiring minimal or no foundation.
Q3: What capacities are available?
A3: Capacities range from 20 TPH to 160 TPH, depending on the model.
Q4: Can the mixing time be adjusted?
A4: Yes, the plant allows adjustable mixing times according to the recipe and required output.
Q5: Are the plants suitable for emergency repair work?
A5: The mobile design and quick setup make it ideal for urgent repair operations.
Gajjar Equipments Pvt. Ltd. is a Exporter of Mobile Asphalt Plant with Quick Installation in Tanzania and including locations in Dar es Salaam, Mwanza, Arusha, Mbeya, Morogoro, Tanga, Kahama, Tabora, Zanzibar City, Kigoma, Dodoma, Sumbawanga, Kasulu, Songea, Moshi, Musoma, Shinyanga, Iringa, Singida, Njombe, Bukoba, Kibaha, Mtwara, Mpanda, Tunduma, Makambako, Babati, Handeni, Lindi, Korogwe, Mafinga, Nansio and many more.
For more information or to request a quote, please contact us.
